Some examples of our work

Below are a few projects we’ve worked on, but of course these are not the only types of work we do. Confidentiality may be important to our client and we have been very careful to show only some approved examples.

Trailer for wheelchair & 3 wheel bike access

Designed and 3D modelled a trailer for a paraplegic client. The trailer will be fully functional via a phone app, the rear door will open, and the floor will lower to ground level to enable the user to enter with their wheelchair. Once in they will then transfer themself on to a 3-wheel racing bike, and upon exit of the trailer it will auto lockup.

Drone environmental study on Kangaroo Island

Drone study to support an environmental impact statement for a potential project on Kangaroo Island to record the site preconstruction and surveying requirements.

Photogrammetry study of plant area for accuracy & fit

Photogrammetry of existing plant and inserting a new 3D model into it to check correctness. In image above you can see existing structures as a point cloud with new plant design added as solid 3D objects.

Special lifting equipment design for military application

Special purpose equipment design and supply for the defence industry, mobile lifting device for the M113 armoured personal carrier with various lifting heads retro fitted to proprietary of the shelf to keep cost minimised.

Purpose built military P3 Orion access platforms

Special Purpose access platforms design and manufactured for the P3 Orion aircraft at Edinburgh airport South Australia.

Procurement/Expediting from Vietnam

Procurement and expediting of cement air slides from Vietnam.

Special Trailer design for M113

Special purpose trailer design and manufacture to transport the M113 armoured personnel carrier around the manufacturing plant in Victoria.

3D Modeling of Caisson

3D modelled new steelwork access, pump bases for an existing pumping caisson structure. This work was to happen in a short shutdown and was 3D modelled to confirm accuracy.

3D Pipe spooling design

Purpose built 3D Modelling of pipe spooling for industrial plant.
